02 CABLE & WIRE CONNECTION

WIRE CONNECTORS

RE-USABLE WIRE CONNECTORS
Packing
Part No Poles Current Voltage Price
(pcs/pkt)
WIRE RANGE : 0.5 - 4.0 mm²; Rigid Single-core ; Rigid Multi-core; Flexible (AWG 22-12)
PC622 2 32A 450V 50 25.00
PC623 3 32A 450V 50 30.50
PC625 5 32A 450V 50 45.00

PUSH-IN WIRE CONNECTORS
Packing
Part No Colour Poles Current Voltage Price
(pcs/pkt)
WIRE RANGE : 0.5 - 2.5 mm²; Rigid Single-core ; Rigid Multi-core
PC212 2 24A 450V 100 18.00
PC213 3 24A 450V 100 24.00
PC214 4 24A 450V 100 36.00
PC215 5 24A 450V 100 38.00
Red Yellow Orange Grey

WIRE CONNECTORS
MATERIAL
Tough thermopastic, UL 94V-2 flame-retardant shell
rated at 105°C (221°F)
2
Dimension (mm) Suitable Wires (mm )
Part No Colour Price
H W D Min Max
WIRE RANGE : 0, 34 - 2, 5mm²
P1 15.2 8.6 6.5 2 x 0, 34 1, 5 + 0, 75 0.08
+ 0, 5
P2 17.7 9.9 7.1 2 x 0, 34 2 x 1, 5 0.12
+ 0, 75
P3 22 12.7 9.7 1 + 0, 5 2 x 2, 5 0.15
+ 0, 75

WIRE RANGE : 0, 34 - 6mm²
P4 24.6 14 11 0, 75 +2 2 x 4 + 2, 5 0.20
x 0, 5
P6 26.5 16.3 13.1 4 x 0, 75 2 x 6 + 0.34
2 x 2, 5

Grey Blue, B Orange Yellow Red
