1.10.6.4 BAU I #4 FAIL*
ACAWS
Condition:

The BAU failed or lost 1553B communications with the MC. The GROUND
affected components or indications will fail and/or change to a default
state depending on the failure mode of the BAU.
TAKEOFF
A. Potential Mission Impacts..................................................... Review

‡ Tuning display for GHC will remain in the last setting with no FIRE/SMK
NORM dimming control. Lighting power will be provided by ISO dc if
power is lost to the BAU.

‡ Flight station edge lighting for one or more panels failed. PRES/OXY
NOT FOR FLIGHT

NOTE
ENG/PROP
These values may remain in their last state if BAU lost
1553 bus communications but is still powered.
FUEL
B. Fault Log............................................................................... Review

GHC DISP CNTL LTS AAR
CKPT EDGE LTS DEGRADED
SPEC AIRCRAFT SERIAL NUMBER ELEC
(End of Procedure)

HYD
1.10.6.5 BAU I #5 FAIL*

Condition: FLT CTRL

The BAU failed or lost 1553B communications with the MC. The
affected components or indications will fail and/or change to a default GEAR
state depending on the failure mode of the BAU.

A. Potential Mission Impacts..................................................... Review DOR/RMP
PERF ‡ *DOOH\ LQGLFDWRU OLJKWV DQG ÀLJKW VWDWLRQ HGJH OLJKWLQJ IRU RQH RU

more panels failed.
JETTISON

NOTE
LANDING
These values may remain in their last state if BAU lost
1553 bus communications but is still powered.
DITCHING
B. Fault Log............................................................................... Review

GALLEY POWER IND, FLT STN EDGE LTS DEGRADED BAILOUT
AIRCRAFT SERIAL NUMBER

OPER (End of Procedure) FAULT LG
