未来的高效 智能分切机 应用领域

Efficient, intelligent slitting machine of the future Application areas

HFQD-L

龙门式高速电脑分切机
HFQD-L series Gantry type automatic 性能特点 Performance characteristics
high-speed computer film slitt
底座、侧板灰铁铸造，牢固可靠。
自动计算卷径实现恒张力控制。
收卷采用前后双气胀轴同向中心收卷方式，
单电机变频驱动，同步带传动，运行平稳可靠，噪音小；
张力控制磁粉离合器收卷，磁粉制动器放卷，张力控制精度高、响应快、可调范围广；
先进的自动纠偏系统，有静电消除装置、吹边装置、收卷自动计米。 印刷包装
分切采用平刀分切（可订做圆刀分切）。
Base and side panel made with solid and endurable grey cast iron.
Constant tension control by automatically calculating the roller diameter.
The central winding with up and down double-air puffing axis in same direction.
Driven by single engine with frequency variation. Timing belt for a smooth, dependable operation with minimal noise
Winding by tension-controlled magnetic powder clutch while unwinding by magnetic powder break with a high precise tension-control, quick response and wide
adjustable range.
The unwinding with advanced simulated photoelectric automatic correction system, and equipped with electrostatic elimination device, edge-blowing device and
winding automatic meter-counting.
Flat blade slitting (round blade by request)

技术参数 Technical parameters

机器型号 Machine type HFQD-L-1300 HFQD-L-1600 HFQD-L-2000
分切卷材最大宽度 Maximum width of slit material 1250mm 1550mm 1950mm
HFQD-II机背面
分切后卷材宽度 Width of material after slitting 30-1250mm 30-1550mm 30-1950mm
HFQD-II machine
最大收卷直径 Maximum rolling diameter Φ600
最大放卷直径 Maximum unrolling diameter Φ800
产品应用 Product application 收卷纸芯直径 Rolling paper core diameter 3inch
放卷纸芯直径 Unrolling paper core diameter 3、6inch
适合分切大直径卷材，如BOPP、BOPA、PET、CPP、CPP/AL、PET/AL、BOPS、PP、PE、PVC等塑料薄膜、复合膜和金属膜，操作简单 分切速度 Speed of slitting 5-400m/min
快捷，运作效率高，性能与国外品牌机相对，性价比高。 分切薄膜厚度 Slit film thickness 12-125um
纠偏误差 Error correction ≤±0.5mm
The machine is suitable for cutting large diameter volume material, such as BOPP, BOPA, PET, CPP, CPP / AL, PET / AL, BOPS, PP, PE, PVC etc. The operation is simple
and quick, the operation efficiency is high, Cost-effective. 随着技术进步以上参数可能更改，如需要最新且详细的参数请联系洪峰销售工人员
With the progress of the above parameters may be changed, such as the need for the latest and detailed parameters, please contact peak sales engineer
