未来的高效 智能分切机 应用领域

Efficient, intelligent slitting machine of the future Application areas

HFQD-CB

透气膜材电脑分切机
Breathable film High-speed computer slitting machine series 机器细节 Details of the machine

德国跟边跟线纠偏系统 恒张力收边机构 手动远程调刀系统 卸料架 除静电装置 卫生材料 医疗材料
German follow-up with the line Constant tension close the edge Manual remote knife Unloading racktension Electrostatic elimination device
correction system adjustment system close the edge

HFQD-CB机背面
HFQD-CB machine
技术参数 Technical parameters

机器型号 Machine type HFQD-CB-1300 HFQD-CB-1600 HFQD-CB-2000
产品应用 Product application
分切卷材最大宽度 Maximum width of slit material 1250mm 1550mm 1950mm
收卷：采用精密气胀滑差轴卷取，自动控制张力及接触辊压力（接触压力可分 Winding by precise air puffing-slip axis, automatic control of tension and 分切后卷材宽度 Width of material after slitting 30-1250mm 30-1550mm 30-1950mm
contact rolls pressure(adjusted by proportioner).
段调节）。 Traction:Constant line speed control. 最大收卷直径 Maximum rolling diameter Φ600
牵引：恒线速度控制。 Unwinding automatically, electric and pneumatic clamping by high precision 最大放卷直径 Maximum unrolling diameter Φ800
放卷：主动放卷、高精度重载顶头电动+气动夹紧，配备升降功能。 and heavy chuck, it equipped with a lifting function.
Edge recycling mode:closed loop tension control flat edge winding system 收卷纸芯直径 Rolling paper core diameter 3inch
边料处理：闭环张力控制平边卷绕系统及吹边系统。 and edge blowing system. 3、6inch
All rollers are active roll eliminating the effect of roller resistance on the
导辊：所有分切导辊均为主动辊，可消除导辊阻力对张力的影响。 tension. 放卷纸芯直径 Unrolling paper core diameter
纠偏系统：采用LPC&EPC(跟边跟线)CCD摄像头静态自动纠偏系统。 LPC & EPC (follow-up with the line), CCD camera static automatic correction 分切速度 Speed of slitting 5-400m/min
system. 12-125um
接料台：气动接料台,用于接驳薄膜。 Film connection platform: pneumatic, equipped for receiving film. 分切薄膜厚度 Slit film thickness
分切方式：配备平刀悬空分切及气动压切圆刀分切。 Slitting mode:Flat knife suspension and pneumatic pressing circular knife 纠偏误差 Error correction ≤±0.5mm
Paper tube alignment device Line laser.
收卷纸管对齐装置：直线导轨移动式一字线形激光。 Meter-counting,automatic stop by setting the length alarm and automatic stop 随着技术进步以上参数可能更改，如需要最新且详细的参数请联系洪峰销售工人员
系统具有计米、定长度停机、放卷少量残余报警及停机等功能。 for shortage of unwinding film materials. With the progress of the above parameters may be changed, such as the need for the latest and detailed parameters, please contact peak sales engineer
