Page 73 - 2020-2021 Racecar Engineering Drag Racing Parts and Accessories Catalog

2020 DRAG RACING

Safety/Driver Equipment

Window Net Installation Kits Allstar Race Suit

Latch Type Round Tube Style, comfort-and affordability! 1-piece double-
layer Allstar Performance race suit is box quilted
ALL10217
with many popular features including side pockets,
an adjustable belt, elastic wrist cuffs, hidden ankle
Lever latch release has a 3/8" round upper support rod for use with cuffs, elastic back panel, adjustable neck strap, and
border and loop-style nets. Mounting brackets are included. a sturdy waist-length zipper. A black nylon bag is in-
cluded. Black Nomex suits are SFI 3.2A/5 certified.
Latch Type Flat Bar Part No. Description
ALL10218 ALL99850 Black, Medium
ALL99851 Black, Large
ALL99852 Black, X-Large
Lever latch release has a 1" x 1/8" x 29" flat steel bar to securely ALL99853 Black, XX-Large
anchor the window net, and mounting brackets. Use with loop-style nets. ALL99862* Custom Size
Will not work with most border type nets. *Completion of an Allstar Custom Racing Suit Order Form is Required.
Part No. Description
ALL99070 Replacement Mounting Tabs
Fire Extinguishers
Spring Loaded Round Tube
Hand-held dry chemical fire extinguish-
ALL10219
ers are perfect for race car, trailer-or
garage use and include steel mounting
bracket and strap, aluminum nozzle,
and hairpin safety pin. ABC-rated,
Spring-loaded tube eliminates the latch release and provides easy entry and mono-ammonium phosphate-based
exit. Pushing against the handle releases or fastens window net. Includes a extinguishers are effective against
9/16" spring-loaded top tube, 3/4" flat aluminum strap for bottom of net, electrical, liquid, grease, wood-or paper
mounting hardware, handle, and instructions. Designed for most border and fires. USCG-approved when used with
loop-style nets. ALL10500
included mounting bracket and retaining
Part No. Description strap to secure extinguisher to bracket.
ALL99071 Replacement Mounting Tabs
Part No. Description ALL10502
ALL10500 2.5 Lb., Red (3" Diameter x 14-1/2" Tall)
Clamp-On Kits
ALL10502 5 Lb., Red (4-3/8" Diameter x 17-1/2" Tall)
Clamp-on kit eliminates welding tabs to chassis.
Clamps have .600" holes designed to install ALL10219 Quick-Release Fire Extinguisher Bracket
window net installation kit to chassis tubing.
ALL10510
Part No. Description
ALL10221 1-1/2" Kit Bracket keeps fire extinguisher secure and
ALL10222 1-3/4" Kit allows quick access by pulling pin. Bracket
Replacement Parts mounts most 2-1/2 lb. extinguishers with
ALL99160 1-1/2" Clamp-On Bracket, Fixed
ALL99161 1-1/2" Clamp-On Bracket, Swivel an O.D. up to 3-1/2" to round tubing with
ALL99162 1-3/4" Clamp-On Bracket, Fixed supplied clamps or fastens to a flat panel
ALL99163 1-3/4" Clamp-On Bracket, Swivel
including trailer or shop walls.
Helmet Hooks
Quick-Release NHRA Fire Extinguisher Bracket
Lightweight aluminum hook clamps on roll cage tubing ALL10512
and provides an anchor for attaching helmet strap.
NHRA-approved bracket keeps fire
Part No. Description
ALL10228 1-1/2" extinguisher secure and allows quick
ALL10229 1-3/4" access by pulling pin. Bracket mounts
ALL10445 Reducer Bushing 1-3/4" To 1-5/8"
most 2-1/2 lb. extinguishers with a 3"
O.D. to 1-1/2"- 1-3/4" round tubing
Universal Helmet Hook with supplied 3/4" wide stainless t-bolt
ALL10223
bands or fastens to a flat panel.
Lightweight, steel universal helmet hook is 1/8" thick and has a
radius mount for attaching to round tubing. Hook may be welded on
or clamped to tube with a standard hose clamp.
