Page 200 - 2020 Allstar Performance Parts and Equipment Catalog

SUSPENSION 2.5" Coil-Over Kits ALL64141

Kits include everything to assemble one complete shock.
Slotted tops allow quick and easy spring changes. Kits are
for 2-1/2" coil-over springs and are designed for use with 2"
steel bodied shocks unless specified.
Kit
Top
Shock Number Replacement Replacement Replacement Replacement
Adjuster Nut
7" Sleeve
5" Sleeve
AFCO
Kit With 7" Sleeve ALL64141 ALL64170 ALL64160 ALL64161 ALL64180
Bilstein
Kit With 7" Sleeve ALL64143 ALL64171 ALL64162 ALL64163 ALL64180
Fox
Kit With 7" Sleeve ALL64130 ALL64177 – ALL64164 ALL64180
Kit For Track Evolution Series With 7" Sleeve ALL64131 ALL64177 – ALL64165 ALL64180
Kit For Aluminum Threaded Body ALL64132 ALL64177 – – –
Integra
(Avenger) Kit With 7" Sleeve ALL64158 – – – ALL64180
JRI
Kit With 7" Sleeve ALL64136 ALL64178 – ALL64169 ALL64180
Koni
Kit With 5" Sleeve ALL64146 ALL64173 ALL64162 ALL64163 ALL64180
Kit With 7" Sleeve ALL64147 ALL64173 ALL64162 ALL64163 ALL64180
Penske
Kit With 7" Sleeve ALL64149 ALL64174 ALL64162 ALL64163 ALL64180
Pro
Kit With 7" Sleeve ALL64151 ALL64175 – ALL64165 ALL64180
QA1
(50 Series) Kit With 7" Sleeve ALL64145 ALL64172 – ALL64165 ALL64180
Kit For Aluminum Smooth Body w/7" Sleeve ALL64154 ALL64172 – ALL64167 ALL64180
Related Products
ALL64182 ..... 2-1/5" C/O Diaper Pin
ALL64183 ..... Snap Ring Flat (Koni)
ALL64184 ..... Snap Ring Round
ALL64186 ..... Snap Ring (Fox)
ALL64182 ALL64183 ALL64184 ALL64186
5" Coil-Over Adapter Shock Extensions
ALL64185 Steel extensions fasten directly to shock shaft for
Aluminum adapter con- added suspension travel. Sold each.
verts existing coil-over M12-1.0 Thread (Bilstein)
kit from a 2-1/2" spring ALL60096..... 1" Extension
to a 5" spring. Adapter inner ALL60097 ..... 2" Extension
hole I.D. is 2-1/2" to work with most 7/16"-20 Thread (Fox)
coil-over sleeves. Sold each, two are ALL60098..... 1" Extension
typically required.
ALL60099 ..... 2" Extension
Spring Spacers Shock Canister Mounts
At last, a shock canister mount that fits all common shock
canisters. Aluminum construction mount is rubber padded
to protect shock canister and increase holding strength.
Adjustable quick release nylon strap will secure any shock
canister from 1-1/2" to 3" in diameter.
Spring spacers can be used with 2-1/2" coil-over springs
or with coil-over kits and 5" adapter when extra spacing ALL64270 ..... 1-1/4" Tubing
ALL64269 ..... 1-3/8" Tubing
is needed. ALL64271 ..... 1-1/2" Tubing
ALL64195 ..... 1" Spacer ALL64272 ..... 1-3/4" Tubing
ALL64196 ..... 2" Spacer ALL64273 ..... Flat Panel
ALL64197 ..... 3" Spacer Replacement Parts
ALL99295 ..... Release Pin ALL64270
ALL99296 ..... Retainer Strap
ALL64273

198 www.allstarperformance.com
