Distribution Region/Path Specification Dialogs

the spline. Specifying a smaller angle makes Line Style Panel
the spline smoother. Specify a larger angle to
draw the spline faster. For information about the settings on this
panel, see “Line Style Panel” on page 301.
Selected Line Panel
Fill Style Panel
The SELECTED LINE panel is available when
the selected edge of the region or path is a The FILL STYLE panel is only available for a
line as opposed to an arc. See “Selected selected Distribution Path if it forms a closed
Edge” on page 214. shape.
Moving the Start of a line segment moves the For information about the settings on this
end of the previous connected line, if there is panel, see “Fill Style Panel” on page 315.
one. Similarly, moving the End of a line
segment moves move the start of the next Arrow Panel
connected line, if there is one. The ARROW panel is only available for
The settings this panel are found in a variety Distribution Paths that do not form a closed
of specification dialogs throughout the shape. For information about the settings on
program. See “Line Panel” on page 300. this panel, see “Arrow Panel” on page 303.

Selected Arc Panel Label Panel

The SELECTED ARC panel is available when Distribution Path labels display in floor plan
the selected edge of the region or path is an and cross section/elevation views when the
arc as opposed to a line. See “Change Line/ “Polylines 3D, Labels” layer is turned on and
Arc” on page 260. use the Text Style assigned to that layer.
The settings on this panel are found in a For more information, see “Label Panel” on
variety of specification dialogs throughout page 682.
the program. See “Arc Panel” on page 309.

1009
