Chief Architect X10 Reference Manual

option is not available for layouts and is both a given layout file and any plan
not normally recommended. See “Line views associated with it.
Weights” on page 1329.
6 A line weight Preview illustrates how
• Select the Line Weight Scale. See “Line changes to the line weight scale affect
Weights and Scaling” on page 1330. This the printed size of various line weights at the
setting should always be the same for current Drawing Scale.

Default Printer for View Dialog

To open the Default Printer for View dialog, • Select a Printer from the drop-down list.
click the Choose button in the Drawing • Choose the Orientation of the paper
Sheet Setup dialog. used by the selected printer.

• Select a Paper Size from the drop-down
list. The options available will depend on
the selected printer.
• Select a Paper Source from the drop-
down list. The options available will
depend on the selected printer.

Customize Sheet Sizes Dialog

To open the Customize Sheet Sizes dialog, Several options are available:
select File> Print> Customize Sheet Sizes, • Click New to create a new sheet size.
or click the Customize button in the
Drawing Sheet Setup dialog. • Select a sheet size and click Copy to cre-
ate a duplicate sheet size.
• Click Delete to remove the selected sheet
size.
• Select a sheet size and click Edit to open
the Edit Paper Size dialog and change its
description, dimensions, and units of
measurement.

1324
