Chief Architect X10 Reference Manual

1 The Name of the selected symbol • Specify the Spray Radius, which is the
object displays here. distance from the sprinkler head that the
spray reaches.
2 Size/Position -
4 Options -
• Specify the Height, Width, and Depth of
the object. Check Reverse Symbol to reverse the
object’s appearance, so that features on its
Note: Some very thin custom symbols may left are positioned on its right, and vice versa.
have a Height, Width, or Depth value of 0. In This turns a right-hand refrigerator, for
these cases, the 0 value cannot be edited. example, into a left-hand refrigerator. This
option has no effect on objects that are
• Check Retain Aspect Ratio to maintain symmetrical.
the ratio between the object’s Height, • Check Include in Schedule to include
Width, and Depth when it is resized in the the selected symbol(s) in the schedule
specification dialog. Does not affect the associated with that type of object. Not
behavior of the object’s edit handles. available for all object types. See “The
• Click Reset Size to reset the symbol’s Schedule Tools” on page 668.
original, unmodified size. The symbol’s • Check Flush Mounted to specify that the
elevation is not affected by this option. selected object follow the pitch of either
• Select the Elevation Reference from the the ceiling or roof. Only available when
drop-down list. This determines where “From Ceiling” or “From Roof” is
the next two settings are measured from selected as the Elevation Reference,
and also affects their setting labels. above.
• Specify the height to Top, measured from If the selected object has a Copyright,
the selected Elevation Reference to the 5 information about it displays here.
top of the object.
• Specify the height to Bottom, measured 6 A preview of the selected library object
displays here and updates with changes.
from the selected Elevation Reference to If the selected symbol is inserted into another
the bottom of the object. object, such as an appliance in a cabinet, the

3 The Sprinkler Settings are only parent object will also display. See “Dialog
available if the selected object is a Preview Panes” on page 42.
sprinkler. See “Sprinkler Tools” on page
1261. Layer Panel
• Specify the Spray Angle, which is the For information about the settings on this
angle within which the sprinkler sprays. tab, see “Layer Panel” on page 195.
An angle of 360° forms a complete circle.

948
