GYRO WRAP

Installation

Waves and Fins Cleaning Material

Hitch Hiker Hubs
5) Remove the Hitch Hiker Waves™ from their packages (below, left). Remove the top retainer plate
and remove the plastic Waves™ from the Hitch Hiker frame assembly (below, center).

Upper Retainer Plate

Frame Assembly

6) Turn the frame assembly upside down and remove the front half of the plastic bushing on both
ends (the side that covers the slotted opening is the front) as shown below, left. Turn frame back
over and place it on top of the white plastic disc. While holding the frame assembly up, replace
lower front side bushing and tighten from the bottom (below, right).

Frame Assembly turned upside-down Lower Retainer Plate

7) Locate the skirts and place one of them on top of the hub assembly. Place a second skirt on top of
the opposite wheel.
