EXPANSION DRYER

Introduction

Before You Get Started

Requirements for installation:
hammer drill with 5/8” (16 mm) bit 25 foot (8 meters) extension cord

tape measure (25 foot [8 meters] or greater) tin snips
level / plumb line safety glasses
miscellaneous hand tools work gloves
fork lift ladder
large “C”- clamps three phase electricity

(2) 120 VAC single phase electricity single-phase @ .5 amp

Equipment included: Qty

Expansion crossbeam weldment 1
Support legs 2
FlowCell™ nozzle assembly (depends on purchase) -

High Side nozzle assembly (depends on purchase) -
Low Side nozzle assembly (depends on purchase) -
Impellers (depends on purchase, see impeller section) -
Accessory box 1

Note: Uncrate and inspect shipment for damage, and to verify that all pieces are there. If there is
any damaged equipment, file a claim with the trucking company immediately. Receiving
party is responsible for filing claim with trucking company. Notify your local distributor or
Belanger, Inc. immediately If shipment is determined damaged or incomplete.

®
