HEXAGON HEAD PANEL SCREWS WITH WASHERS
Hexagon head panel screws with
spring and flat washers.

Material: Steel
d ₂ Finish: Zinc Yellow (A3C)
SW Black (A3S)
Washer: Spring and Flat
S
L

Tensile Dia Pitch Length SW Dimens. of Washer Zinc Yellow Black Pack
Strength mm mm L mm mm d2 mm S mm Art. No. Art. No. Qty.
12 0129 230 612 0129 220 612
16 0129 230 616 0129 240 616
6 1.00 20 10 14 2.5 0129 230 620 0129 220 620
4.6
25 0129 230 625 0129 220 625 100/
30 0129 230 630 0129 220 630 300
0129 230 825 0129 240 825
8.8 8 1.25 25 12 18 3.2 0129 270 825 0129 280 825
4.6 10 30 14 22 7.0 0129 211 003 0129 221 003

HEXAGON HEAD PANEL SCREWS WITH WASHER
Hexagon head panel screws with flat
washer.

Material: Steel
Finish: Zinc Yellow (A3C)
H E Black (A3S)
D Washer: Flat
Tensile Strength: 4.6
SW L

Dia Pitch L SW H D E Zinc Yellow Black Pack
mm mm mm mm mm mm mm Art. No. Art. No. Qty.
6 1.0 20 10 19 3.8 4.3 0129 250 620 0129 200 620
8 1.25 25 10 22 3.0 6.1 0129 250 825 0129 200 825 50/
5 0.8 14 8 14 3 3.8 - 0129 200 515 100
6 1.0 18 10 18 2 4.3 - 0129 200 616
