ST-2 Steering system- Steering Mechanism
Preparation
Recommended tools
Picture Name Applicable range
Measurement of clearance between the
Dial Gauge steering knuckle inner diameter and the
intermediate steering shaft, and radial runout
Measurement of outer diameters of the
Vernier calipers
steering knuckle pin and sleeve
Measurement of the steering knuckle
Spring scale
starting torque
Measurement of the steering knuckle
Feeler
clearances
Ball joint disassembly tool
Disassembly of the ball joint
Removal and installation of the steering
Bush punch
knuckle sleeve
ST-002
