BW - 74 Body - Inner and outer trims

d. Install the steering shaft cover, and install and tighten the
mounting screws and plastic expansion screws.

e. Install the steering column. (refer to Chapter ST steering system- steering gear–steering columns,
replacement)
f. Install the transmission operation mechanism assembly. (refer to Chapter TR transmission and controlling
mechanism-manual transmission-transmission assembly-transmission controlling mechanism, replacement)

g. Install the glove box assembly and deputy dashboard. (refer to Chapter BW body- instrument panel,
combination instrument, ashtray- auxiliary instrument, replacement)
h. Install B pillar lower guard. (refer to Chapter BW body- windshield, window glass- interior & exterior trim
–side wall inner shield, replacement)
i. Install the lower seatbelt mounting bolts. (refer to Chapter BW body- safety belt– driver/assistant seat belt,
replacement)

j. Install the co-driver seat. (refer to Chapter BW body- seat– assistant seat, replacement)
k. Install the driver seat. (refer to Chapter BW body- seat– driver seat, replacement)

4. Install the left and right front door threshold pressing
strips
a. Install the left and right front door threshold pressing
strips, and install and tighten the door threshold pressing
strip mounting screws.
b. Install the threshold pressing strip mounting screw block
covers.
c. Install the door seal.

BW-074
