Body - Inner and outer trims BW - 115

Change IN
Caution
Replacement method for right and left pedals is the same. DI

EG
1. Remove the secondary pedal
a. Flip the cab and remove the front wheel fender and
TR
front wheel arch assembly. (refer to Chapter BW body-
interior & exterior trim – wheel trim, replacement)
b. Remove the mounting bolts outside of the primary pedal AX
body.
FR

ST
c. Remove the mounting bolts in the front and back brackets
of the primary pedal body, and remove the primary pedal
and secondary pedal pads. BR

BW

EL

d. Remove the front and rear bracket mounting bolts of the
secondary pedal and remove the front and rear brackets of
the secondary pedal.

2. Install the secondary pedal
a. Install the front and rear brackets of the secondary pedal,
and install and tighten the mounting bolts.

BW-115
