EL - 144 Electrical system –circuit
IN
This stands for soldering point inside the power consuming appliances and switch.
10 Branching point When in harness, this stands for splicing wire and current is branched through that
DI point.
11 System name Differentiate different systems and functions according to the names for easy inquiry
EG
To describe the value or working status of the electrical component to provide reference
12 Maintenance guide
during troubleshooting.
TR
To indicate the reference page of the harness (location of electrical component and the
13 Part position
directions of associated harness in the vehicle).
AX
Connector between To indicate the reference page of the harness where the two connector pieces are
14
harnesses connected (harness with female piece first, then harness with male piece).
FR
To indicate the reference location of the connection point between the return wire of
15 Grounding
electrical component and the metallic body part of the vehicle.
