Electrical system –circuit EL - 205
Low beam lamp position: pins 2-4 are activitated. IN
High beam lamp position: pins 2-3 are activitated.
Overtaking position: pins 1-6 are activitated. DI
: Part position
EG
Number Refer to harness Number Refer to harness
F101 Frame harness B034 Body harness
TR
B004 Body harness B070 Body harness
B012 Body harness B100 Body harness AX
: Connector between harnesses
FR
Number Number Refer to harness (connector position)
Body harness and frame harness (instrument
B021 F008 ST
panel left lower, close to the clutch pedal)
: Grounding
BR
Number Grounding point position Number Grounding point position
B005 Front wall left side grounding B069 Front wall right side grounding BW
B007 Body left side ground point 1
EL
EL-205
