Electrical system –circuit EL - 253
IN
DI
EG
TR
AX
FR
ST
BR
15494596 DELPHI
F099 to engine ECU
BW
Terminal Terminal
Color Function Color Function
number number
Engine ECU module battery constant EL
1 Red 48 Red - Blue Urea pump temperature signal
power supply
White -
2 Electric ground 49 - -
black
Engine ECU module battery constant
3 Red 50 - -
power supply
White -
4 Electric ground 51 - -
black
Engine ECU module battery constant
5 Red 52 - -
power supply
White -
6 Electric ground 53 Red - Green Urea heating signal
black
Green -
7 - - 54 Exhaust braking relay coil -
black
8 - - 55 - -
Green
9 Starter relay control signal 56 - -
- white
Urea metering valve-/start/pre-heating
10 - - 57 Pink-black
relay grounding
Red -
11 - - 58 Manual braking switch signal
Yellow
12 - - 59 Green - red Cruise deceleration switch signal
Control signal of air controlled solenoid
13 Pink 60 - -
valve
14 - - 61 - -
15 White- red Ignition switch ON power supply 62 Green CAN-H
16 - - 63 - -
17 - - 64 - -
EL-253
