EL - 292 Electrical system –circuit
IN
F042 Front end of power supply main switch F067 Intake temperature sensor
DI
F044 To storage battery's positive role F070 Secondary startup switch
F045 Back end of power supply main switch F071 Secondary flameout switch
EG
F046 Dryer F088 To adblue pump
TR F057 NOX sensor F099 To engine ECU
F061 Urea tank urea level temperature sensor F100 To two-way fuse box
AX
F062 Urea tank heater F101 To vehicle frame fuse box
F063 Air valve F102 Pre-heater relay
FR
F065 SCR intake air temperature sensor F105 NOX sensor terminal resistor
ST
F plug & socket connector between vehicle frame harnesses
BR
F001 Connect to frame harness B F015 To transmission harness
F003 Connect to frame harness F F041 Connect to tail harness 1
BW
F004 Connect to frame harness E F047 Connect to tail harness 2
EL F005 Connect to frame harness I F103 To end B of preheating relay
F008 Connect to frame harness A F104 To end L of preheating relay
F the vehicle frame harness – earthing point
F012 Earthing of the vehicle frame harness F043 Battery negative pole wiring post
