05-62 VEHICLE MAINTENNANCE - REPLACEMENT

CHANGE THE AUTOMATIC TRANSMISSION LUBRICATING OIL

1 . Turn off ignition switch
2 . Lift up the vehicle

3 . Screw out the transmission bottom drain
plug and discharge the transmission
lubricating oil.
NOTICE
05

• Before discharge, make sure that the vent
plug is unobstructed.

• When discharging the transmission
lubricating oil, use a dedicated vessel to
receive the transmission lubricating oil,
ftwx051009 and dispose it as required.
fuwx04105
• After the transmission lubricating oil is
discharged, refit the drain plug, and avoid
forgetting this.

Torque : 12 N•m

4 . Screw out the transmission filler plug

fuwx04106
ftwx051010
5 . Use the tool to fill the transmission
lubricating oil from the transmission
lubricating oil filler hole
Transmission lubricating oil (model): ATF
M-1375.4

ftwx051011
fuwx04107
