62-12 SUPPLEMENTAL RESTRAINT SYSTEM - DRIVER AIRBAG

(j) Press the tool trigger and deploy the airbag.

DANGER
Make sure it is clear within 10 meters of the
driver airbag assembly.
NOTICE
62
When the indicator lamp is on, the driver airbag
assembly will be deployed.
NOTICE

When the indicator lamp is on, the driver airbag
assembly will be deployed.

(k) Loose the cables and remove the driver
airbag assembly.
(l) Put the assembly into a plastic bag and seal
it.

DANGER

• The airbag will become very hot once
depoyed.Therefore, leave it for at least 30
minutes before proceeding.
• Wear gloves and safety goggles when
handling a deployed airbag.
• Do not pour water to a driver airbag
assembly with an deployed airbag.
• Be sure to wash your hands with water
after the operation.
