WIRING - DISCRIPTION OF HARNESS CONNECTORS 71-155

Engine electrical control module (diesel)

NO. Color Function Remark NO. Color Function Remark
Red - yel- Battery power
1 30 – – Blocked
low supply
2 Black Earthing 31 – – Blocked

Red - yel- Battery power
3 32 – – Blocked
low supply
Purple - High speed fan
4 Black Earthing 33
yellow control
Red - yel- Battery power
5 34 Pink ECM feedback
low supply

6 Black Earthing 35 – –

7 – – 36 - - 71
8 – – 37 Purple-red -

9 – – 38 – –

Green -
10 – – 39 Clutch switch
black
A/C medium
11 Brown 40 – –
voltage switch

Manual regen-
Red -
12 Blue-white erative switch 41 brown Ignition power
Signal input

Electronic gas
blue–Yel- pedal 2 power
13 - – 42
low supply The out-
put

Electronic gas
Blue - yel-
14 white- red CAN_H 43 pedal 2 signal
low
The input
Blue - or- Electronic gas
15 yellow- blue CAN_L 44
ange pedal 1 signal

16 – – 45 – –
Preheating re-
17 – – 46 White
lay control
Yellow - Low speed fan
18 – – 47
purple control
Yellow -
19 – - 48 A/C grant signal
green
