71-218 WIRING - DISCRIPTION OF HARNESS CONNECTORS
D008 Acceleration sensor D009 Front passenger seat belt
pretensioner
NO. Color Function Remark
NO. Color Function Remark
Brown - yel-
1 Earthing
low Green - Right seat belt
1 black pretensioner -
71 Green - yel-
2 Signal
low Green - Right seat belt
2
Purple - yel- Power sup- red pretensioner +
3
low ply
D010 Front right door lamp switch D011 Rear right door lamp switch
NO. Color Function Remark NO. Color Function Remark
Right front Right rear
Purple -
1 door pedal 1 Green door pedal
red
light- light -
2 Purple Earthing Yellow -
2 Earthing
black
