WIRING - DISCRIPTION OF HARNESS CONNECTORS 71-245
H401 To floor harnesses
NO. Color Function Remark NO. Color Function Remark
Rear right door
1 Blue Unlocking 8 Pink
speaker-
Rear right door
2 Brown Locking 9 Orange
speaker+
White - or- Power window Rear right door
3 10 Green
ange switch step lamp-
Red - yel- Rear right door
4 Blue Backlighting + 11
low step lamp+
5 Orange Up+ 12 - -
6 Sky blue Down + 13 - -
7 Black Earthing 71
