pneumatic conveying systems
VACUUM/PRESSURE SYSTEMS ECO PHASE PNEUMATIC
COMBINATION DILUTE PHASE CONVEYING SYSTEMS
FEATURES FEATURES
• MULTIPLE PICK-UP POINTS TO MULTIPLE • REDUCED ENERGY CONSUMPTION
DESTINATIONS • MAXIMIZES THE BEST ATTRIBUTES OF DILUTE
• INSTALLED FOR UNLOADING RAIL AND DENSE PHASE CONVEYING
CARS AND HOPPER TRUCKS • CONSTANT DELIVERY OF MATERIAL
SLIDE DIVERTER
VALVE BIN VENT
FILTER
SLIDE BIN VENT
BIN VENT DIVERTER FILTER
FILTER VALVE
FILTER
STORAGE F BIN VENT
SILOS
VACUUM
BREAKER
B FILTER
RECEIVER LEVEL PRESSURE
INDICATORS E BLOWER
PACKAGE
A AIRLIFT RAIL-CAR
DISCHARGE ADAPTERS VACUUM BIN ACTIVATOR
BLOWER
PACKAGE TRUCK FILL LINE
PRESSURE MAGVEYOR ROTARY
VALVE
BLOWER D ECO-PHASE AIRLOCK
PACKAGE C ROTARY TRANSMITTER
VALVE
AIRLOCK
STORAGE SILO CUSTOMER
PROCESS
C ROTARY VALVE AIRLOCK D MAGVEYOR
WITH CAVITY AIR PURGE • Unique technology
• Reduces abrasion on rotor, • Patented
A RAIL CAR UNLOADING B FILTER RECEIVER cylinder and end plates • Continuous Feed E PRESSURE BLOWER PACKAGE F BIN VENT
• For use with vacuum unload systems • Material-Air Separator • Purges material from between • No ASME Code vessel required • Positive displacement blower • Material-air separator
• Portable, easily handled by one person • Filter bags or cartridges end shroud and end plates • High Solids loadings • Pressures to 15 psig • Pulse jet filter
• Designed for up to 17 inches Hg • Patented design • Lower Velocities • Up to 15 Hg
• Minimal material degradation
