pneumatic conveying systems
DENSE PHASE PNEUMATIC
CONVEYING SYSTEMS

B SLIDE FEATURES
DIVERTER C BIN VENTS
VALVE • GOOD FOR ABRASIVE OR DEGRADING PRODUCTS
• CONVEYS IN BATCH MODE
• USES COMPRESSED AIR
LEVEL
INDICATORS
• NO ROTARY VALVE AIRLOCK REQUIRED
BIN VENT
SILOS
TRUCK FILL LINE
A DENSE PHASE
TRANSMITTER
DIVERTER
VALVE
CUSTOMER
PROCESS
A DENSE PHASE TRANSMITTER
• High pressure capabilities
• Exclusive air management system
E HIGH PRESSURE SLIDE DIVERTER VALVE C BIN VENT • Boosters or air trace lines not required
• Up to 100 PSI • Material-air separator
• 14-degree diversion angle for minimal • Pulse jet filter
pressure loss • Up to 15 Hg
• Two-way, bi-directional flow
WATCH PRODUCT FLOW IN A
DENSE PHASE CONVEY LINE:
YOUTUBE.COM/WATCH?V=KSXZTF7VJCM
