JOYSTICK RIGGING
JPO BULKHEAD PLATE - FITTINGS NOT INCLUDED BULKHEAD FITTING - PRESSURE LINE - LONG
8M0146247
Improved bulkhead plate with threaded passage for multiple hose installations.
Joystick, multiple Hose Installations.
FITTINGS
BULKHEAD FITTING - RETURN LINE - SHORT
22-8M6001497
Required for all JPO systems. Pressure line, 3 inch thickness.
BULKHEAD FITTING - 90 DEGREE RETURN LINE
22-8M6001488
Required for all JPO systems. Return line, .75 inch thickness.
BULKHEAD FITTING - RETURN LINE - LONG
22-8M0031467
Used on top of bulkhead fittings. .5 inch female to .5 inch male.
BULKHEAD FITTING - 90 DEGREE PRESSURE LINE
22-8M6002264
Required for all JPO systems. Return line, 3 inch thickness. 22-8M0031539
BULKHEAD FITTING - PRESSURE LINE - SHORT
JOYSTICK RIGGING Used on top of bulkhead fittings. .375 inch female to .375 inch male.
STEERING CYLINDER FITTING - STRAIGHT RETURN
LINE
22-8M6001495
Required for all JPO systems. Pressure line, .75 inch thickness.
22-8M2007090
This straight fitting can be used to replace the standard 90 degree cylinder fitting
for some installs where needed. .375 inch male to .5 inch male.
