defining project orgAnizAtion 55

Figure 2.49
section properties
and extents

Figure 2.50
detail sections
in plan view

Certification Also note the color of callout and section heads in Figure 2.50. These blue icons act
Objective as hyperlinks to the other views in your project. The great thing about them is they are
automatically coordinated numerically when you place the views on sheets in your
document set.
If you open the view of the Building section, you’ll see that the Detail sections are graphically
the opposite of what you’ve seen in plan view (Figure 2.51).
