Drop into place over the ledgers and are secured with a locking device to
prevent movement. Act as conventional transoms but extend beyond the in-
side ledger to provide intermediate support to one or two inside boards.

Standards available in sizes

Single Board Support

Locates in the cup joint and provides support for a single inside board at a vertical. It replaces the
inside board transom at that point.

Standards available in sizes

Hop-up Brackets

Designed to increase the overall width of the working platform to seven or eight
boards by supporting two or three additional boards beyond the inner face of the

scaffold. They incorporate a cup joint at the outside end to allow the fitting of an
inside ledger which links the hop-up brackets and supports intermediate tran-

soms. Also incorporates a facility to support a handrail post.

Weight (kg) Diameter (mm)

0.09 8

Standards available in sizes

Return Device

A conventional blade end connected to a hook sec-
tion which locates over the ledger on the adjacent

return elevation to provide a corner connection. Used
in pairs.

Standards available in sizes

Description Weight (kg) Diameter (mm)
Steel 7.0 200
Rubber 6.7 200

Swivel Face Brace

Participant Handbook : Scaffolding 37
