Standards available in sizes

Size/ hop up –O- type

Side/Hop-Up Brack- ets are used to ex-
tend the working platform closer to the
building structure in cases where the

main scaffold cannot be erected directly
next to the working face.

Standards available in sizes

Height (m) Weight (kg)
2.4 5.0

3.0 7.0
3.6 9.0
4.2 11.0
4.8 13.0
5.4 15.0
6.0 17.0

Side/ console bracket –O-type

Side/Console brackets are used at the end of any scaffold

to extend or widen the reach.

Standards available in sizes

Length (m) Weight (kg)

1.065 9.15

2.13 2.13
