Bay length (m) Weight (kg)

2.13 10.01

2.43 10.67

3.05 11.99

Standards available in sizes

Length (m) Weight (kg)
0.65 2.15

0.88 2.82
1.065 3.36

1.15 3.6

1.57 4.82

1.82 5.28
2.13 6.03

2.43 7.34
3.05 9.11

Truss Ledger –O–type

The Truss Ledger has been designed to enable higher service loads to
be applied to the scaffold than could be applied to regular ledgers. The

reinforcing tube and stiffener plates support the top tube and provide
strength while maintaining lightness.

Standards available in sizes

Weight (kg)

0.87

Participant Handbook : Scaffolding 53
