The Swivel jack is used as a starting base for a scaffold. It is adjustable in height and angle to
allow for compensation on uneven surfaces so that a level scaffold is always attainable.

Length (m) Weight (kg)

0.88 4.55
1.065 5.33

1.15 5.64
1.57 7.17

1.82 8.12
2.13 9.21

2.43 10.30

3.05 12.56

Standards available in sizes

Castor 8”:-

Height (m) Weight (kg)

0.50 3.32

The 8” Castor is designed to provide mobility to a small to medium

size scaffold tower allowing the tower to roll across flat surfaces.

Standards available in sizes

Description Length (m) Weight (kg)

Ledger to plank – 1 plank 0.240 3.47

Ledger to plank – 2 plank 0.480 4.33

Ledger to plank – 3 plank 0.720 5.18

Participant Handbook : Scaffolding 50
