PROFINET System bus
Input 1 Input 2 1: TD+ connection 1: TD+ Block diagram of an input
2: RD+ 2: TD--
4 4 4
3 1 3 1 3: TD– 3 5 1 3: RD--
2 2 4: RD– 2 4: RD+ Digital Input Supply
Housing: Shield 5: GND X1 ... X8
M12 D coded M12 B coded Housing: Shield
M12
1
3
10 11 12 Boot / Execute Digital Input 1: 24 V M8
Reset
Operation panel 123456789 Device Name 3 4 1 M8 3 4 1 3: 0 V U LS — + 3 Input 0 ... 7 Logic
X1 ... X8
1
Device Name Instance
2⁶ Address
2⁵
2⁴
2³
ON 2² 2¹ 2⁰ 4: Input 4 270 pF 270 pF Error F
<___
USB Supply
COM Input Output 1: 24 V U
1: +5 V 2: 24 V U LS
4 2 2: –Data 2 2 3: 0 V U A Module
3 1 3: +Data 3 1 1 3 4: 0 V U LS mount
4: GND 4 4 A
M8 Housing: Shield M12 A coded

Technical Data Technical Data
Digital inputs: Process image: 6
Number of inputs 8 Input process image 1024 bytes
Connection type (2) M8 connectors, 3 poles Output process image 1024 bytes
Wire connection 2- or 3-wire LED indicators:
Input filter parametrizable BF : PROFINET IO bus error LED (red)
Input characteristic Type 1, acc. to IEC 61131-2 DIA : PROFINET IO diagnostics LED (red)
Signal voltage (0) -3 V ... +5 V DC ACT/LNK 1 : Network connection,
Signal voltage (1) +15 V ... +30 V DC fieldbus 1 LED (green)
Input wiring high-side switching ACT/LNK 2 : Network connection,
Input voltage 24 V DC (-30 V DC < U IN < +30 V DC) fieldbus 2 LED (green)
Input current (typ.) 2.8 mA CS : Fieldbus coupler status LED (green/red)
Cable length, unshielded ≤ 30 m SBM : System bus master status LED (green/red)
Wrong connection of inputs No effect F: Error status LED (red)
System bus: 0 ... 7: Input signal status LED (yellow)
Number of expendable modules 64 U LS + U A : Supply status LED (green)
Connection type (3) M12 connectors, B coded, 5 poles, Indicators Non-latching
shielded
Isolation:
Channel – Channel No
U LS , U A , system bus, fieldbus 500 V DC each
Service:
Type USB standard 1.1
Connection type (5) M8 connectors, 4 poles
Standards and approvals:
PROFINET IEC 61158
Conformity marking 1
Korea Certification
r UL 508
Configurable functions:
Fieldbus coupler see manual
Digital Inputs
Input filter (per channel) 0.1/ 0.5/ 3 /15 /20 ms/ filter off
Inversion (per channel) On/off
Online simulation (per channel) Lock/unlock, simulation value: 0/1
Online simulation (per module) Diagnostics
I/O diagnostics:
I/O diagnostics (per module) Short circuit/overload of sensor supply General Specifications
Undervoltage (U LS + U A )
Dimensions (mm) W x H x L 75 x 35.7 x 117
Weight 377.1 g
