PROFIBUS System bus
Input Output 1: +5 V * connection 1: TD+ Block diagram of an input
2: Line A 2: TD--
4 4 4
1 3 3 1 3: GND * 3 5 1 3: RD--
2 2 4: Line B 2 4: RD+ Digital Input Supply
5: GND X1 ... X8
M12 B coded Housing: Shield M12 B coded Housing: Shield
*Internal signal M12
1
3
10 11 12 Boot / Execute Digital inputs 1: 24 V M8
Reset
Operation panel 123456789 SSA 3 4 1 M8 3 4 1 3: 0 V U LS — + 3 Input 0 ... 7 Logic
X1 ... X8
1

2⁶ Address
2⁵
2⁴
2³
2¹
ON 2² 4: Input 4 270 pF 270 pF Error F
2⁰
<___
USB Supply
COM Input Output 1: 24 V U
1: +5 V 2: 24 V U LS
4 2 2: –Data 2 2 3: 0 V U A Module
3 1 3 1 1 3 LS mount
3: +Data 4 4 4: 0 V U
4: GND A
M8 Housing: Shield M12 A coded

Technical Data Technical Data
Digital inputs: Process image: 6
Number of inputs 8 Input process image 244 bytes
Connection type (2) M8 connectors, 3 poles Output process image 244 bytes
Wire connection 2- or 3-wire LED indicators:
Input filter parametrizable RUN : Fieldbus coupler initialization LED (green/red)
Input characteristic Type 1, acc. to IEC 61131-2 BF : PROFIBUS DP bus error LED (red)
Signal voltage (0) -3 V ... +5 V DC DIA : PROFIBUS DP diagnostics LED (red)
Signal voltage (1) +15 V ... +30 V DC BUS : PROFIBUS DP projecting error LED (red)
Input wiring high-side switching CS : Fieldbus coupler status LED (green/red)
Input voltage 24 V DC (-30 V DC < U IN < +30 V DC) SBM : System bus master status LED (green/red)
Input current (typ.) 2.8 mA F: Error status LED (red)
Cable length, unshielded ≤ 30 m 0 ... 7: Input signal status LED (yellow)
Wrong connection of inputs No effect U LS + U A : Supply status LED (green)
System bus: Indicators Non-latching
Number of expendable modules 63
Connection type (3) M12 connectors, B coded, 5 poles,
shielded
Isolation:
Channel – Channel No
U LS , U A , system bus, fieldbus 500 V DC each
Service:
Type USB standard 1.1
Connection type (5) M8 connectors, 4 poles
Standards and approvals:
PROFIBUS IEC 61158
Conformity marking 1
Korea Certification
r UL 508
Configurable functions:
Fieldbus coupler see manual
Digital Inputs
Input filter (per channel) 0.1/ 0.5/ 3 /15 /20 ms/ filter off
Inversion (per channel) On/off
Online simulation (per channel) Lock/unlock, simulation value: 0/1
Online simulation (per module) Diagnostics
I/O diagnostics:
I/O diagnostics (per module) Short circuit/overload of sensor supply General Specifications
Undervoltage (U LS + U A )
Dimensions (mm) W x H x L 75 x 35.7 x 117
Weight 405 g
