Suction Cups for High-Temperature Applications
Bellows Suction Cups SAOB HT2 (Oval, 1.5 Folds)
PA01019111_inh_EN.pdf Suction area (LxW) 60 x 30 mm and 80 x 40 mm PA01019111_inh_EN.pdf

container
Schmalz - The Company Suitable for Industry Specific Applications

container
Applications
Vacuum Knowledge • Oval bellows suction cup with 1.5 folds for most dynamic
handling of hot metal sheets up to 250° C
• Unloading e.g. of elongated workpieces after forming, e.g.
reinfored ribs and plates
Vacuum Suction Cups • Handling of formed sheet metal parts; fold structure allows
optimal adjustment

• Handling of thin aluminum sheets without deformation or deep
drawing
Special Grippers • For use e.g. in feeder systems for press lines in the automobile
industry
Vacuum Grip- ping Systems Bellows suction cups SAOB HT2 (oval, 1.5 folds) Design

container

• Robust, wear-resistant oval bellows suction cup SAOB with
Mounting Elements 1.5 folds made of HT2, single sealing lip and inner support
• Connection nipple glued to the reinforcing element of the suction
cup (very high strength and temperature resistance)
Vacuum Generators

Valve Technology

System design bellows suction cup SAOB HT2 (oval, 1.5 folds)
Switches and Monitoring container Our Highlights... Your Benefits...

• Silicone-free special material >Absence of PWIS (paint wet-
ting impairment substances),
HT2
Filters and Connections up to 250° C temperature
resistance long term
• Large, structured inner >No deep-drawing of the work-
support piece; capable of handling
high lateral forces
Services • Soft and flexible sealing lip >Good sealing of even slightly
curved surfaces
• 1.5 folds >Optimum adaptation to
curved workpieces, very good
Contact Bellows suction cups SAOB HT2 for handling formed sheet metal parts damping

• Stiff top fold >Resistance to lateral forces
and high horizontal
accelerations
Index of Products

280 www.schmalz.com/saob-ht2
