Needle Grippers
Needle Grippers SNG-AP
PA01019111_inh_EN.pdf Needle stroke max. 3 mm to max. 20 mm (variable) PA01019111_inh_EN.pdf

container

container Designation Code Needle Grippers SNG-AP Schmalz - The
Abbreviated designation Number of needles Needle diameter Product addition Needle stroke Company
in mm in mm
Example SNG-AP 10 0.8 V 3:
SNG-AP 10 0.8 V 3
SNG-AP 10 0.8 V variable needle 3 Knowledge
1.2 stroke 10 Vacuum
20

container
Vacuum
Ordering Data Needle Grippers SNG-AP Suction Cups
Needle gripper SNG-AP is delivered assembled. The product consists of:
container
• Gripper of type SNG-AP – available with various needle diameters and strokes
Available spare parts: needle modules, maintenance cover Special Grippers
Available accessories: mounting plate, holder system, add-on kit sensor
Vacuum Grip- ping Systems
container
Needle Grippers SNG-AP
container
Type Part Number
SNG-AP 10 0.8 V 3 10.01.29.00340
SNG-AP 10 1.2 V 3 10.01.29.00377
SNG-AP 10 0.8 V 10 10.01.29.00361 Mounting Elements
SNG-AP 10 1.2 V 10 10.01.29.00381
SNG-AP 10 1.2 V 20 10.01.29.00362

container
Ordering Data Accessories Needle Grippers SNG-AP Vacuum Generators
container
Type Mounting plate* Holder system A2* Holder system A3* Add-on kit sensor** STV-W***
SNG-AP 10 0.8 V 3 10.01.29.00403 10.01.29.00402 10.01.29.00322 10.01.29.00400 10.08.02.00296
SNG-AP 10 1.2 V 3 10.01.29.00403 10.01.29.00402 10.01.29.00322 10.01.29.00400 10.08.02.00296 Technology
SNG-AP 10 0.8 V 10 10.01.29.00403 10.01.29.00402 10.01.29.00322 10.01.29.00400 10.08.02.00296 Valve
SNG-AP 10 1.2 V 10 10.01.29.00403 10.01.29.00402 10.01.29.00322 10.01.29.00400 10.08.02.00296
SNG-AP 10 1.2 V 20 10.01.29.00403 10.01.29.00402 10.01.29.00322 10.01.29.00400 10.08.02.00296
*complete with mounting screws Switches and
**Set of sensor and mounting element Monitoring
***Note: suitable screw in push fittings can be found under "Screw in push fittings" in section "Filters and Connections"

container
Filters and Connections
Ordering Data Spare Parts Needle Grippers SNG-AP
container
Type Needle modules* Maintenance coverage**
SNG-AP 10 0.8 V 3 10.01.29.00405 10.01.29.00419
SNG-AP 10 1.2 V 3 10.01.29.00406 10.01.29.00419
SNG-AP 10 0.8 V 10 10.01.29.00407 10.01.29.00420 Services
SNG-AP 10 1.2 V 10 10.01.29.00408 10.01.29.00420
SNG-AP 10 1.2 V 20 10.01.29.00409 10.01.29.00421
*Set of two needle housings with needles
**Set of two coverages
Contact

Index of Products

container
www.schmalz.com/sng-ap
