Needle Grippers
Needle Grippers SNG-AP
PA01019111_inh_EN.pdf Needle stroke max. 3 mm to max. 20 mm (variable) PA01019111_inh_EN.pdf

container
Schmalz - The Company Suitable for Industry Specific Applications

container
Applications
Vacuum Knowledge • Needle gripper for handling non-rigid and highly porous materials
(primarily textiles)
• Handling materials that are difficult to grip using vacuum such as
composite textiles, fleece, filter materials, insulation and foam
Vacuum Suction Cups materials etc.
• Flexible handling of materials with changing stacking height due
to free selectable stroke adjustment
Special Grippers

Vacuum Grip- ping Systems Needle grippers SNG-AP Design

container

• Driven by double-acting pneumatic cylinders
Mounting Elements • High-strength housing with lightweight design (1)

• Three sizes with needle strokes of max. 3 mm, 10 mm or 20 mm
• Adjustment wheel (2) with scale for continuous, simultaneous
stroke adjustment
Vacuum Generators • Ten needles (3) with diameters of 0.8 mm or 1.2 mm (depending
on the model)
• Insertion angle of 30° or 45° (depending on the model)
Valve Technology System design needle grippers SNG-AP • Optional sensors for monitoring the needle end positions
• Can also be mounted with the Schmalz holder system HTS
Switches and Monitoring container Our Highlights... Your Benefits...

• Intersecting needles and small >Safe handling, even of small
gripping area
and very unstable workpieces
Filters and Connections • Low weight and double- >High acceleration for
acting pneumatic cylinders
minimized cycle times
• Tool-free simultaneous >Individual adaptation to
needle stroke adjustment up different workpiece
to a maximum of 20 mm geometries; fast start of
Services • One central pneumatic drive >Synchronous extension and
operations and set-up time
retraction of the needles;
reduces the need for
couplings and hoses
Contact • Blow off function for fast and >High level of process
Needle grippers SNG-AP being used for handling composite textiles
reliable load release reliability and exact
positioning; short cycle times
Index of Products • Quick and tool-free cleaning >Low maintenance
of the needles and replacing
the needle modules
330 www.schmalz.com/sng-ap
