Needle Grippers
Needle Grippers SNG-V
PA01019111_inh_EN.pdf Needle stroke 0 mm to 7 mm (variable) PA01019111_inh_EN.pdf

container

container Designation Code Needle Grippers SNG-V Schmalz - The
Abbreviated designation Number of needles Needle diameter Product addition Needle stroke Company
in mm in mm
Example SNG-V 10 1.2 V 7:
SNG-V 10 1.2 V 7
SNG-V 10 1.2 V variable needle 7 Knowledge
stroke Vacuum
V-HT variable needle
stroke and high-
temperature
Vacuum Suction Cups

container
Ordering Data Needle Grippers SNG-V
Special
Needle gripper SNG-V is delivered assembled. Grippers
container
Available spare parts: needle module
Vacuum Grip- ping Systems
Available accessories: mounting plate

container
Needle Grippers SNG-V
container
Type Part Number
SNG-V 10 1.2 V 7 10.01.29.00176 Mounting Elements
SNG-V 10 1.2 V-HT 7* 10.01.29.00428
*For operating temperatures from 5 to 150 °C and a maximum workpiece temperature of 260 °C

Vacuum
container
Ordering Data Accessories Needle Grippers SNG-V Generators
container
Type* Mounting plate**
SNG-V 10 1.2 V 7 10.01.29.00093
SNG-V 10 1.2 V-HT 7 10.01.29.00093 Technology
*Note: suitable screw in push fittings can be found under "Screw in push fittings" in section "Filters and Connections" Valve
**Including mounting screws
Switches and
container
Ordering Data Spare Parts Needle Grippers SNG-V Monitoring
container
Type Needle module*
SNG-V 10 1.2 V 7 10.01.29.00238
SNG-V 10 1.2 V-HT 7 10.01.29.00464 Filters and Connections
*Set of 2 needle modules with needles

container
Technical Data Needle Grippers SNG-V
container Services
Type Number of Needle Additional Pressure range Operating Installation Weight
needles diameter function (operating temperature position [g]
[mm] pressure) [bar] [°C]
SNG-V 10 1.2 V 7 10 1.2 Variable stroke 3.0 ... 7.0 5 ... 60 Any 265
SNG-V 10 1.2 V-HT 7 10 1.2 Variable stroke, 3.0 ... 7.0 5 ... 150 Any 255 Contact
high temperature

Index of Products

container
www.schmalz.com/sng-v
container 335
