S E R I ES A V A L V ES

AIR BLEEDER OPERATED

Bleeder Operated

Both air pilot and bleeder operated valves can be applied
when electrical control is impractical or hazardous. The
bleeder can be used in place of the air pilot model where
limited space prohibits the external pilot pressure supply
required by the external pilot control valves.
Model 7919 Bleeder Operators
Air Bleeder Operated
#6000, Plunger type bleeder operator is used when striking
force is straight on. #8492, Ball type bleeder operator has a
hardened ball for cam actuation.

OPTIONS:
• Two position detent
(adds 5/8” to overall length)

INTEGRATED POWER PACKAGE

The integrated power package is a sub-base assembly in which the Series A valve is
assembled directly to any square head tie rod type air cylinder.
Since only one air supply connection is required, assembly times can be greatly reduced.
AC sub-bases include metering valves and muffler to keep the Integrated Power Package
a neat, compact cylinder and valve combination. The AC valve increases the overall
height of the cylinder by only 3 inches.
