WINSTA MIDI special 4
®
Distribution Connectors, 4-Pole
181

400 V/6 kV/3
I 25 A 4
N

1 Approvals

4
Description Color Item No. Pack. Unit
Distribution connector, Distribution connector, 3-way, 1 x plug/3 x socket
4-pole
gray 770-1734 50
light green 770-1735 50
pink 770-1736 50
For additional pole marking, see page 287.
Item-Specific Accessories
Mounting plate, for distribution connectors

black 770-624 25
white 770-674 25
Fixing pin, for mounting plates

2 black 890-601 250
3 black 770-601 250
Lockout cap, for socket, separable, 12-pole

black 770-201 100
white 770-221 100
Lockout cap, for plug, separable, 5-pole

yellow 770-360 100

Dimensions

<________46________>
<_____36,7_____>

<______ 40 ______>
