P. 259
WINSTA — Distribution Boxes 10
®
Supply Cable Entry, Distribution, Three-Phase to Single-Phase Current (400 V/230 V)
1 Input (Terminal Strip, 5-Pole), 6 Outputs (3-Pole), Coding A, WINSTA MIDI 257
®
Description:
Power supply is performed via standard
5-pole terminal strip. The phases L , L and L L1 PE N L2 PE N L3 PE N
3
2
1
of the three-phase current are divided into 3
single-phase circuits with 2 outputs each.
PE N L1 L2 L3
Includes: One cable clamp and two fixing
screws
N PE L1 N PE L2 N PE L3
I 25 A
N
250 V / 4 kV / 3
400 V / 6 kV / 3
Internal wiring: 4 mm 2
Pack.
WINSTA L1 PE N L2 PE N L3 PE N Item Color Item No. Unit
®
Distribution Box PE N L1 L2 L3 Distribution box, white 899-681/123-000
N PE L1 N PE L2 N PE L3 1
Supply Cable Entry, Distribution, Three-Phase to Single-Phase Current (400 V/230 V)
1 Input (Terminal Strip, 5-Pole), 6 Outputs (3-Pole), Coding P, WINSTA MIDI
®
Description:
Power supply is performed via standard
5-pole terminal strip. The phases L , L and L L1 PE N L2 PE N L3 PE N
3
1
2
of the three-phase current are divided into 3
single-phase circuits with 2 outputs each.
10
PE N L1 L2 L3
Includes: One cable clamp and two fixing
screws
N PE L1 N PE L2 N PE L3
I 25 A
N
250 V / 4 kV / 3
400 V / 6 kV / 3
Internal wiring: 4 mm 2
Pack.
®
WINSTA L1 PE N L2 PE N L3 PE N Item Color Item No. Unit
Distribution Box PE N L1 L2 L3 Distribution box, black 899-631/339-000 1
N PE L1 N PE L2 N PE L3
WINSTA — perfectly plugged!
®
