Male Connectors with Snap-In Flanges
MCS MIDI 5
357

Pin spacing: 7.5 mm / 0.295 in.

0.08–2.5 mm 2 28–12 AWG
630 V/6 kV/2 12A 300 V/ 15 A

<_____________ L _____________> <______ 27,3>
5
) 13,3 )
)
<
<_
17,5 14,4 14,9
<________ L <________ _> > <_ 2 ) <___ ) <__ 1,2 5
1,5
<_____________ L 4 _____________>
<_____________ L A _____________>
<________ L 3 <_______ _>
15 +0,1
( 4,1 ) ( 10,5 ) <_ <_______ L B ±0,1 _______>
( 7,5 ) 5 ( )
L = (pole no. – 1) x pin spacing + 8.2 mm Male connectors with snap-in flanges for feedthrough
L = L – 0.2 mm applications, for 0.5 to 2.5 mm plate thickness.
3
L = L + 15.2 mm
4
3
L = L + 18 mm
5
3
L = L + 12.6 mm
3
A
L = L + 13.2 mm
B 3
Pole No. Item No. Pack.
Unit
Male connector with snap-in flanges,
7.5 mm pin spacing, light gray
without preceding with preceding ground
ground contact contact and marking
2 723-602/114-000 50
3 723-603/114-000 723-603/114-042 50
4 723-604/114-000 723-604/114-042 50
5 723-605/114-000 723-605/114-042 25
6 723-606/114-000 25
7 723-607/114-000 25
8 723-608/114-000 25
9 723-609/114-000 25
10 723-610/114-000 10
11 723-611/114-000 10
12 723-612/114-000 10 1 3 3

1 3 3 1 2 3 4
Preceding ground (earth) position and printing on the headers
3-pole 4-pole 5-pole
1 3 3 1 2 3 4 1 2 3 4 5

1 2 3 4 1 2 3 4 5

For other lengths, please contact factory.
