X-COM -SYSTEM
®
6 1-Conductor/1-Pin and 2-Pin Disconnect Carrier Terminal Blocks
316
0.08 - 4 mm² AWG 28 - 12
400 V/6 kV/3 1 300 V, 20 AU 400 V/6 kV/3 1 600 V, 20 AU
I N 16 A 2 300 V, 20 A2 I N 16 A 2 300 V, 20 A2
Terminal block width 5 mm / 0.197 in Terminal block width 5 mm / 0.197 in
L 8 - 9 mm / 0.33 in 3

1 400 V = rated voltage
6 kV = rated surge voltage
3 = pollution degree
250 V/4 kV/3 =
ominal voltage with shield contact
(also see Section 14)
<_ 28,5 mm/ _> 1.12 in <_ 28,5 mm/ _> 1.12 in 3 Strip length, see packaging or instructions.
2 16 A, 85°C upper temperature limit (see
current-carrying capacity curve at www.wago.com)
4 See application notes for:
Insulation stop, page 293
( 29,5 mm/1.16 in ) ( 29,5 mm/1.16 in ) 5 Note:
<____ 52,5 mm/2.07 in _____> <____ 52,5 mm/2.07 in _____> 2-conductor female plug is not suitable.
Pack. Pack. Accessories
Item No. Item No.
Unit Unit
1-conductor/1-pin disconnect carrier terminal block, 2-pin disconnect carrier terminal block,
for DIN 35 rail, acc. to EN 60715 for DIN 35 rail, acc. to EN 60715
gray 769-232 50 gray 769-222 50 Miniature WSB Quick marking system, plain,
10 strips with 10 markers per card,
1-conductor/1-pin disconnect carrier terminal block 2-pin disconnect carrier terminal block with shield 5 mm wide markers
with shield contact, (no picture), contact, (no picture), yellow 248-501/000-002
for DIN 35 rail, acc. to EN 60715 for DIN 35 rail, acc. to EN 60715 red 248-501/000-005
gray 769-233 1 50 gray 769-223 1 50 blue 248-501/000-006
Item-Specific Accessories Item-Specific Accessories gray 248-501/000-007
orange 248-501/000-012
End and intermediate plate, 1.1 mm thick End and intermediate plate, 1.1 mm thick light green 248-501/000-017
orange 769-308 100 (4x25) orange 769-306 100 (4x25) green 248-501/000-023
gray 769-307 100 (4x25) gray 769-305 100 (4x25) violet 248-501/000-024
5
Insulation stop, Screwless end stop,
4 5 pcs/strip, for DIN 35 rail,
0.08 - 0.2 mm² “s” (0.14 mm² “f-st”) 6 mm wide
white 769-470 200 (8x25) gray 249-116 100 (4x25)
Insulation stop, Screwless end stop,
4 5 pcs/strip, for DIN 35 rail,
0.25 - 0.5 mm² 10 mm wide
light gray 769-471 200 (8x25) gray 249-117 50 (2x25)
Insulation stop,
4 5 pcs/strip,
0.75 - 1 mm²
dark gray 769-472 200 (8x25)
Protective warning marker,
with high-voltage symbol, black,
for 5 terminal blocks
yellow 280-415 100 (4x25)
Test plug,
with 500 mm cable,
2 mm Ø
red 210-136 50
769 Series Accessories
Appropriate marking system:
Miniature WSB (see Section 13)
Coding pin, 1-conductor female plug,
for coding female plugs 5 straight
orange 769-435 100 (4x25) gray 769-101 200
Test plug, 1-conductor female plug,
with 500 mm cable, angled
2.3 mm Ø gray 769-101/022-000
yellow 210-137 50 200
Disconnect lock, Miniature WSB Quick marking system,
for disconnect tab used on 280/281 and 10 strips with 10 markers per card,
769 Series disconnect terminal blocks 5 mm wide markers
red 709-170 200 (8x25) plain 248-501 5
Certification organizations can be found in the overview on pages 622 and 623.
