X-COM -SYSTEM
®
6 1-Conductor/1-Pin and 2-Pin Diode Carrier Terminal Blocks
318
0.08 - 4 mm² AWG 28 - 12
U N 250 V, U RM 1000 V U N 250 V, U RM 1000 V
1N4007 - 0.5 A continuous current 1N4007 - 0.5 A continuous current
Terminal block width 5 mm / 0.197 in Terminal block width 5 mm / 0.197 in
L 8 - 9 mm / 0.33 in 1

< 28,5 mm / > 1.12 in < 28,5 mm / > 1.12 in 1 Strip length, see packaging or instructions.

2 See application notes for:
Insulation stop, page 293
( 29,5 mm/1.6 in ) ( 29,5 mm/1.6 in ) 3 Note:
<___ 52,5 mm/2.07 in _____> <___ 52,5 mm/2.07 in _____> 2-conductor female plug is not suitable.
Circuit I Circuit II Circuit I Circuit II
Accessories

Miniature WSB Quick marking system,
10 strips with 10 markers per card,
5 mm wide markers
plain 248-501 5
Pack. Pack. Miniature WSB Quick marking system, plain,
Item No. Unit Item No. Unit 10 strips with 10 markers per card,
1-conductor/1-pin diode carrier terminal block, 2-pin diode carrier terminal block, 5 mm wide markers
for DIN 35 rail, acc. to EN 60715 for DIN 35 rail, acc. to EN 60715 yellow 248-501/000-002
Anode right 769-238/281-411 100 Anode right 769-228/281-411 100 red 248-501/000-005
Anode left 769-238/281-410 100 Anode left 769-228/281-410 100 blue 248-501/000-006
Item-Specific Accessories Item-Specific Accessories gray 248-501/000-007
orange 248-501/000-012
End and intermediate plate, 1.1 mm thick End and intermediate plate, 1.1 mm thick light green 248-501/000-017
orange 769-308 100 (4x25) orange 769-306 100 (4x25) green 248-501/000-023
gray 769-307 100 (4x25) gray 769-305 100 (4x25) violet 248-501/000-024
5
Insulation stop, Screwless end stop,
2 5 pcs/strip, for DIN 35 rail,
0.08 - 0.2 mm² “s” (0.14 mm² “f-st”) 6 mm wide
white 769-470 200 (8x25) gray 249-116 100 (4x25)
Insulation stop, Screwless end stop,
2 5 pcs/strip, for DIN 35 rail,
0.25 - 0.5 mm² 10 mm wide
light gray 769-471 200 (8x25) gray 249-117 50 (2x25)
Insulation stop,
2 5 pcs/strip,
0.75 - 1 mm²
dark gray 769-472 200 (8x25)
Protective warning marker,
with high-voltage symbol, black,
for 5 terminal blocks
yellow 280-415 100 (4x25)
Test plug,
with 500 mm cable,
2 mm Ø
red 210-136 50
769 Series Accessories
Appropriate marking system:
Miniature WSB (see Section 13)
Coding pin, 1-conductor female plug,
for coding female plugs 3 straight
orange 769-435 100 (4x25) gray 769-101 200
Test plug, 1-conductor female plug,
with 500 mm cable, angled
2.3 mm Ø gray 769-101/022-000
yellow 210-137 50 200
Certification organizations can be found in the overview on pages 622 and 623.
