P. 442
Power Supply Connectors, 6- and 7-Pole S
9 294 Series
440
without ground contact without ground contact
Pack. Pack.
Item No. Item No.
Unit Unit
Terminal block for field connection without ground Terminal block for field connection without ground
contact, contact,
without snap-in mounting feet, without snap-in mounting feet,
6-pole, white 7-pole, white
plain 294-4006 250 plain 294-4007 200
<____ _ 27,3 _ ____> <13,9 > <____ _ 27,3 _ ____> <13,9 >
(_10 _) <_17 ±0,2 _> (_10 _) <_17 ±0,2 _>
<_______________ 60 ________________> <_______________ 70 ________________>
Dimensions in mm Dimensions in mm
Certification organizations can be found in the overview on pages 622 and 623.
