with snap-in ground contact with angled snap-in ground contact

Pack. Pack.
Item No. Item No.
Unit Unit
Terminal block for field connection with snap-in Terminal block for field connection with angled
ground contact, snap-in ground contact,
with snap-in mounting feet, with snap-in mounting feet,
4-pole, white 4-pole, white
1/L´-2/L-PE-N 294-5224 500 1/L´-2/L-PE-N 294-5324 500
1-2-PE-N 294-5214 500 1-2-PE-N 294-5314 500

Terminal block for field connection without snap-in Terminal block for field connection with angled
ground contact, snap-in ground contact,
without snap-in mounting feet, without snap-in mounting feet,
4-pole, white 4-pole, white
1/L´-2/L-PE-N 294-4224 500 1/L´-2/L-PE-N 294-4324 500
1-2-PE-N 294-4214 500 1-2-PE-N 294-4314 500

9

2,35
> <____
> 5,2 <

<____ _ 27,3 _ ____> <13,9 ><_____ 25 ___ __> <____ _ 27,3 _ ____> <13,9 ><_____ 25 ___ __>

(_10 _) <_17 ±0,2 _> (_10 _) <_17 ±0,2 _>
<___________ 40 ____________> 4,53 ____> > <___________ 40 ____________> 4,53 ____> >
Dimensions in mm Dimensions in mm
