The application assumes that the rotation direction, pole numbering direction and slot
numbering direction are clockwise when viewed from the connection end of the machine. To
set a counter-clockwise rotation or numbering direction, set the correct checkbox on the
Mechanical Ratings page.
Figure 6-3 IAM Asset General Properties
Figure 6-4 IAM Asset Winding Properties
