Page 1986 - Master Catalog 2017, Inch

P. 1986

Lightning Service
™
Specials from Blanks • VariTap • HSS-E
™

(continued)
Specials from Blanks • VariTap • HSS-E

max D pitch
style oxide ﬂ utes L L3 L2 D limit min
M11
Spiral-Point Gun — Plug 72136 3 3.160 0.880 – 0.323 13 0.30
Spiral-Flute — Modiﬁ ed Bottom 83176 3 3.160 0.500 – 0.323 13 0.30
Extended-Length
Spiral-Flute — Modiﬁ ed Bottom 68492 3 6.000 0.880 – 0.323 13 0.30
M12
Spiral-Point Gun — Plug 83062 3 3.380 0.920 – 0.367 15 0.30
Spiral-Flute — Modiﬁ ed Bottom 83080 3 3.380 0.570 – 0.367 15 0.30
Extended-Length
Spiral-Flute — Modiﬁ ed Bottom 68493 3 6.000 0.920 – 0.367 15 0.30
M12.5
Extended-Length
Spiral-Flute — Modiﬁ ed Bottom 68494 3 6.000 0.920 – 0.367 15 0.30
M14
Spiral-Point Gun — Plug 83064 3 3.590 0.980 – 0.429 15 0.40
Spiral-Flute — Modiﬁ ed Bottom 83082 3 3.590 0.630 – 0.429 15 0.40
M15
Spiral-Point Gun — Plug 83199 3 3.810 1.060 – 0.480 15 0.40
M16
Spiral-Point Gun — Plug 83066 3 3.810 1.060 – 0.480 15 0.40
Spiral-Flute — Modiﬁ ed Bottom 83084 3 3.810 0.690 – 0.480 15 0.40
M18
Spiral-Point Gun — Plug 83068 3 4.030 1.070 – 0.542 15 0.40
Spiral-Flute — Modiﬁ ed Bottom 83086 3 4.030 0.610 – 0.542 15 0.40

Pricing Based on Order Quantity Five day lead time.
min max
1 1
2 2
3 5
6 8
9 11
12 23
24 47
48 72
Lightning Service

W288 widia.com
