Lightning Service
Specials from Blanks • EM-NI • HSS-E-PM

(continued)
Specials from Blanks • EM-NI • HSS-E-PM

oxide max D pitch
style nitride fl utes L L3 L2 D limit min
M2
Spiral-Point Gun — Plug 68479 2 1.75 0.44 – 0.141 11 0.30
Spiral-Flute — 3 to 4 Pitches 83177 2 1.75 0.44 – 0.141 13 0.30
M2.2
Spiral-Point Gun — Plug 68439 2 1.75 0.44 – 0.141 11 0.30
Spiral-Flute — 3 to 4 Pitches 72055 3 1.75 0.44 – 0.141 13 0.30
M2.5
Spiral-Point Gun — Plug 83200 2 1.81 0.50 – 0.141 11 0.30
M3
Spiral-Point Gun — Plug 83181 2 1.94 0.37 0.62 0.141 13 0.30
Spiral-Flute — 3 to 4 Pitches 83171 3 1.94 0.37 0.62 0.141 13 0.30
M3.5
Spiral-Point Gun — Plug 83166 3 2.00 0.39 0.81 0.141 13 0.30
Spiral-Flute — 3 to 4 Pitches 72144 3 2.00 0.39 0.81 0.141 13 0.30
M4
Spiral-Point Gun — Plug 83180 3 2.13 0.43 0.87 0.168 13 0.30
Spiral-Flute — 3 to 4 Pitches 72119 3 2.13 0.43 0.87 0.168 13 0.30
M5
Spiral-Point Gun — Plug 83470 3 2.38 0.51 1.06 0.194 13 0.30
Spiral-Flute — 3 to 4 Pitches 72108 3 2.38 0.51 1.06 0.194 13 0.30
M6
Spiral-Point Gun — Plug 72067 3 2.50 0.56 1.23 0.255 13 0.30
Spiral-Flute — 3 to 4 Pitches 83157 3 2.50 0.56 1.23 0.255 13 0.30
M6.3
Spiral-Point Gun — Plug 72061 3 2.50 0.56 1.23 0.255 13 0.30
M7
Spiral-Point Gun — Plug 72075 3 2.72 0.63 1.39 0.318 13 0.30
Spiral-Flute — 3 to 4 Pitches 72143 3 2.72 0.63 1.39 0.318 13 0.30
M8
Spiral-Point Gun — Plug 83469 3 2.72 0.63 1.39 0.318 13 0.30
Spiral-Flute — 3 to 4 Pitches 83154 3 2.72 0.63 1.39 0.318 13 0.30
M9
Spiral-Point Gun — Plug 83202 3 2.94 0.71 1.55 0.381 13 0.30
Spiral-Flute — 3 to 4 Pitches 83160 3 2.94 0.71 1.55 0.381 13 0.30
M10
Spiral-Point Gun — Plug 72083 3 2.94 0.71 1.55 0.381 13 0.30
Spiral-Flute — 3 to 4 Pitches 83158 3 2.94 0.71 1.55 0.381 13 0.30
M11 83185 3 3 3.16 0.88 – – 0.323 15 0.30
Spiral-Point Gun — Plug
Lightning Service M12 72078 3 3 3.38 0.92 – – 0.367 15 0.30
83167
0.323
0.30
15
3.16
0.88
Spiral-Flute — 3 to 4 Pitches
Spiral-Point Gun — Plug
15
3.38
83159
0.92
0.367
0.30
Spiral-Flute — 3 to 4 Pitches
M14
Spiral-Point Gun — Plug
0.98
0.429
72211
0.40
3.59
15
Spiral-Flute — 3 to 4 Pitches 72158 3 3 3.59 0.98 – – 0.429 15 0.40
M16
Spiral-Point Gun — Plug 83161 3 3.81 1.06 – 0.480 15 0.40
Spiral-Flute — 3 to 4 Pitches 68461 4 3.81 1.06 – 0.480 15 0.40
M18
Spiral-Flute — 3 to 4 Pitches 72212 4 4.03 1.07 – 0.541 15 0.40
Pricing Based on Order Quantity Five day lead time.
min max
1 1
2 2
3 5
6 8
9 11
12 23
24 47
48 72
W290 widia.com
