Specials from Blanks • EM-TI • HSS-E-PM

(continued)
Specials from Blanks • EM-TI • HSS-E-PM

max D pitch
style nitride fl utes L L3 L2 D limit min
M3
LH Spiral-Flute — Plug 72017 3 1.94 0.37 0.62 0.141 13 0.30
RH Spiral-Flute — 3 to 4 Pitches 72087 3 1.94 0.37 0.62 0.141 13 0.30
M3.5
LH Spiral-Flute — Plug 83151 3 2.00 0.39 0.81 0.141 13 0.30
M4
LH Spiral-Flute — Plug 72059 3 2.13 0.43 0.87 0.168 13 0.30
RH Spiral-Flute — 3 to 4 Pitches 83183 3 2.13 0.43 0.87 0.168 13 0.30
M4.5
RH Spiral-Flute — 3 to 4 Pitches 83184 3 2.38 0.51 1.06 0.194 13 0.30
M5
LH Spiral-Flute — Plug 83152 3 2.38 0.51 1.06 0.194 13 0.30
RH Spiral-Flute — 3 to 4 Pitches 83153 3 2.38 0.51 1.06 0.194 13 0.30
M6
LH Spiral-Flute — Plug 83165 3 2.50 0.56 1.23 0.255 13 0.30
RH Spiral-Flute — 3 to 4 Pitches 83150 3 2.50 0.56 1.23 0.255 13 0.30
M8
RH Spiral-Flute — 3 to 4 Pitches 68353 3 – – – – 13 0.30
M10
LH Spiral-Flute — Plug 83156 3 2.94 0.71 1.55 0.381 13 0.30
RH Spiral-Flute — 3 to 4 Pitches 83468 3 2.94 0.71 1.55 0.381 13 0.30
M12
LH Spiral-Flute — Plug 83170 3 3.38 0.92 – 0.367 15 0.30
RH Spiral-Flute — 3 to 4 Pitches 83162 3 3.38 0.92 – 0.367 15 0.30

Pricing Based on Order Quantity Five day lead time.
min max
1 1
2 2
3 5
6 8
9 11
12 23
24 47
48 72
